EKA 3W Cargo (EKA 1700K) – Electric Three-Wheeler Cargo by EKA Mobility
 – Electric Three-Wheeler 1.png)
 – Electric Three-Wheeler 2.png)
 – Electric Three-Wheeler 3.png)
 – Electric Three-Wheeler 4.png)
Specifications
|
Specification |
Details |
|
Vehicle Model |
EKA 3W Cargo (EKA 1700K) |
|
Vehicle Category |
L5N |
|
Chassis |
Ladder |
|
Seating Capacity |
D + 2 |
|
GVW |
1700 kg |
|
Payload |
750 kg |
|
Vehicle L x W x H |
3950 x 1580 x 2400 mm |
|
Wheelbase |
2550 mm |
|
Ground Clearance |
172 mm |
|
Turning Radius |
5 m |
|
Body Type |
Sturdy MS/AL Body |
|
Container Dimensions |
2300 x 1550 x 1750 mm |
|
Container Volume |
220 ft3 |
|
Fuel Type |
Electric |
|
Application |
Electric Three-Wheeler Cargo |
|
Max Speed |
50 kmph |
|
Vehicle Warranty |
3 Years or 125,000 km (whichever is earlier) |
|
Battery Warranty |
6 Years or 165,000 km (whichever is earlier) |
Frame & Drivetrain
|
Specification |
Details |
|
Traction Motor Type |
eAxle |
|
Peak Power |
15 kW |
|
Peak Torque |
80 Nm |
|
Battery Type |
Lithium Ferrous Phosphate (LFP) |
|
Battery Capacity |
20 kWhr |
|
Operating Voltage |
51.2 V |
|
Charging |
Single Phase AC Charging, DC Fast Charging |
|
Charging Socket |
AC: 3 Pin 16 Amp; DC: Type 6 Connector |
|
Charging Time |
AC: 6.5 hrs; DC: 3 hrs |
|
Range |
200 km |
|
Gradeability |
19% |
|
Transmission |
EV Motor Drive |
Suspension & Brakes
|
Specification |
Details |
|
Steering |
Rack & Pinion Steering Wheel |
|
Front Suspension |
Dual Helical Spring with Damper |
|
Rear Suspension |
Shocker Absorber with Torsion Bar |
|
Brakes |
Front: Disc Brakes; Rear: Drum Brakes |
Wheels & Tyres
|
Specification |
Details |
|
Tyre Size |
Tubeless, 130/80 R12 |
Components & Features
|
Specification |
Details |
|
Hill Hold Assist |
Yes |
|
Product Highlights |
Rugged Build: Ladder-frame Chassis, eAxle, Helical Spring Suspension with Damper Front & Torsion Bar Rear, First-in-Class 20 kWh Battery, Centrally Mounted Battery Pack; Comfortable Cabin; Smart Safety; Advanced Efficiency |
