Eicher Starline Next 2050 D AC Diesel – Eicher Trucks and Buses School Bus Chassis
Specifications
|
Specification |
Details |
|
Bus Model |
Starline Next 2050 D AC |
|
Seating Capacity (2x2) |
21+1+D |
|
Seating Capacity (3x2) |
25+1+D |
|
Wheelbase, mm |
3100 |
|
Overall length, mm |
5970 |
|
Overall width, mm |
2164 |
|
Overall height, mm |
2975 |
|
Front overhang, mm |
1200 |
|
Rear overhang, mm |
1670 |
|
Turning circle diameter, m |
12.2 |
|
Engine |
E366 |
|
Displacement, cc |
1999 |
|
Power |
75 kW @ 3200 Rpm |
|
Torque |
285 Nm @ 1250 – 2500 Rpm |
|
Clutch diameter, mm |
275 |
|
Transmission |
ET30S5 |
|
Transmission type |
Synchromesh (5 Speed + 1 Rev) |
|
GVW, t |
5.6 |
|
Chassis frame |
BSK 46 |
|
Chassis C frame dimensions, mm |
180x60x5 |
|
Fuel tank capacity, L |
60 |
|
Brakes |
Hydraulic with Disc |
|
Tyres |
7.50 x 16 -16 PR |
|
Suspension - front |
Semi elliptic |
|
Suspension - rear |
Semi elliptic |
|
Steering |
Power steering |
|
Battery |
12V 130Ah |
|
Alternator |
2 x 110A |
|
Floor type |
Button type Vinyl |
|
DEF tank capacity, L |
19 |
|
Fuel Type |
Diesel |
|
Application |
School Buses |
Components & Features
|
Specification |
Details |
|
Efficiency Feature |
Fuel Coaching |
|
Performance Feature |
MBooster+ |
|
Steering Feature |
Cruise control |
|
Telematics Feature |
Eicher Live telematics system |
|
Safety Feature |
Seat belts for all passengers |
|
Safety Feature |
Emergency exit |
|
Safety Feature |
Reinforced body structure |
|
Safety Feature |
Anti-slip flooring |
|
Safety Feature |
School bus signage and stop arm |
|
Safety Feature |
First-aid kit |
|
Comfort Feature |
Air conditioning (AC) unit |
