Eicher Pro 6028T Diesel – Heavy-Duty Tipper Truck by Eicher Trucks and Buses
Specifications
|
Specification |
Details |
|
Truck Model |
Pro 6028T |
|
GVW |
28 t |
|
Fuel Tank Capacity |
220 litre |
|
DEF Tank Capacity |
33 litre |
|
Electricals & Battery |
24V; 120AH |
|
Fuel |
Diesel |
|
Application |
Heavy-Duty Tipper Truck |
|
Engine Model |
VEDX8, BS-VI |
|
Displacement |
7700 cc |
|
Max Power |
194 kW @ 2200 rpm |
|
Max Torque |
1000 Nm @ 1000-1700 rpm |
|
Emission Standard |
BS VI |
|
Gearbox |
ET 140S9 |
|
Gear Type |
9 Speed |
Frame & Drivetrain
|
Specification |
Details |
|
Clutch Type & Diameter |
430 mm, Pull Type, Single Dry Plate |
|
Front Axle |
Forged Reverse Elliot Type |
|
Rear Axle |
VECV 440DH Single Reduction Tandem Fully Floating Banjo |
|
Rear Axle Ratio |
5.29 |
|
Differential Lock |
Inter-axle lock |
|
Chassis Dimensions |
300 x 90 x 8 mm with 5 Full length inner liner |
|
Wheelbase |
4000 mm, 4585 mm |
|
Cargo Body |
14 Cum (Rock Body), 16 Cum (Box Body), 20 Cum (Box Body) |
|
Minimum Ground Clearance |
255 mm |
|
Turning Circle Diameter |
14.3 m, 16.3 m |
Suspension & Brakes
|
Specification |
Details |
|
Front Suspension |
Parabolic |
|
Rear Suspension |
Bogie |
|
Service Brake |
S-Cam Dual line with ABS |
|
Parking Brake |
Pneumatically operated hand control valve |
|
Gradeability |
52% - Crawler Gear |
|
Steering Type |
Tilt and Telescopic Power steering |
Wheels & Tyres
|
Specification |
Details |
|
Tyres |
11x20 (Nylon, Mining, Radial) |
Components & Features
|
Specification |
Details |
|
Performance Feature |
MBooster+ |
|
Steering Feature |
Cruise Control |
|
Telematics Feature |
Eicher Live telematics system |
