Eicher Pro 6028 Diesel – Heavy-Duty Rigid Haulage Truck by Eicher Trucks and Buses
Specifications
|
Specification |
Details |
|
Truck Model |
Pro 6028 |
|
GVW |
28 t |
|
Cargo Body |
CBC, CWC, HSD |
|
Fuel Tank |
350 litre |
|
DEF Tank |
50 litre |
|
Battery |
24 V |
|
Fuel |
Diesel |
|
Application |
Heavy-Duty Rigid Haulage Truck |
|
Engine Model |
VEDX5 - BSVI |
|
Displacement |
5700 cc |
|
Max Power |
154.5 kW @ 2200 rpm |
|
Max Torque |
825 Nm @ 1200-1600 rpm |
|
Emission Standard |
BS VI |
|
Gearbox |
ET90S6, Manual |
Frame & Drivetrain
|
Specification |
Details |
|
Clutch Diameter |
395 mm |
|
Rear Axle |
Heavy Duty fully floating single reduction, 458 mm drive head |
|
Final Drive Ratio |
4.8 |
|
Chassis Dimensions |
300 x 76 x 6 mm |
|
Cargo Body Length (Internal) |
7317 mm, 7745 mm, 7336 mm, 9422 mm, 9850 mm |
|
Wheelbase |
5350 mm, 6800 mm |
Suspension & Brakes
|
Specification |
Details |
|
Front Suspension |
Parabolic |
|
Rear Suspension |
Semi elliptic Slipper |
|
Brakes |
Dual circuit full air ‘S’ Cam with ABS |
|
Gradeability |
21% |
|
Steering |
Tilt and telescopic Power Steering |
Wheels & Tyres
|
Specification |
Details |
|
Tyres |
Front: 295/90R20, Rear: 10R20 |
Components & Features
|
Specification |
Details |
|
Efficiency Feature |
Fuel Coaching |
|
Performance Feature |
MBooster+ |
|
Steering Feature |
Cruise Control |
|
Telematics Feature |
Eicher Live telematics system |
