Eicher Pro 3014 Diesel – Medium-Duty Truck by Eicher Trucks and Buses
Specifications
|
Specification |
Details |
|
Truck Model |
Pro 3014 |
|
GVW |
14.25 t |
|
Cargo Body |
CBC/HSD |
|
Engine |
E494 4 Cyl 4V CRS BSVI |
|
Max. Power Output |
120 kW @ 2600 rpm |
|
Max. Torque Output |
500 Nm @ 1200-1800 rpm |
|
Emission Standard |
BS VI |
|
Fuel Tank Capacity |
190 litre, 425 litre |
|
Battery |
12V - 100Ah |
|
Fuel Type |
Diesel |
|
Maintenance Interval |
80000 kms |
|
Warranty |
3 Years/Unlimited KMs on vehicle, 4 Years/Unlimited KMs on Engine and Gearbox |
|
Application |
Medium-Duty Truck |
Frame & Drivetrain
|
Specification |
Details |
|
Displacement |
3800 cc |
|
Gearbox |
ET 50S7 |
|
Gear Shift |
7 Speed |
|
Clutch Diameter |
330 mm |
|
Ground Clearance |
220 mm |
|
Wheelbase |
4550 mm, 5550 mm |
|
Cargo Body Length (Internal) |
5808 mm, 6112 mm, 6782 mm, 7364 mm |
|
Cargo Body Width (Internal) |
2125 mm, 2338 mm |
Suspension & Brakes
|
Specification |
Details |
|
Suspension Front |
Parabolic with shock absorber |
|
Suspension Rear |
Semi-elliptical laminated leaves with helper spring |
|
Brakes (Service) |
Full Air brake divided line with auto slack adjuster at all wheel ends and APDA |
|
Gradeability |
25% |
|
Steering |
Hydraulic Assisted Power Steering (Tilt & Telescopic) |
Wheels & Tyres
|
Specification |
Details |
|
Tyre Size |
8.25R20 - 16PR Radial Tyres |
Components & Features
|
Specification |
Details |
|
Efficiency Feature |
Fuel Coaching |
|
Performance Feature |
MBooster+ |
|
Steering Feature |
Cruise Control |
|
Telematics Feature |
Eicher Live telematics system |
