Specification

Details

Bus Model

6016 N LPO

Wheelbase, mm

5840

Overall Length, mm

11460

Overall Width, mm

2540

Overall Height, mm

2728

Ground Clearance, mm

240

Front Overhang, mm

2205

Rear Overhang, mm

3415

Turning Circle Diameter, m

22.7

Engine Make

VEDX5

Displacement, cc

5132

Power

155 kW @ 2200 RPM

Torque

825 Nm @ 1200-1600 RPM

Clutch Diameter, mm

395

Transmission Make

ET70S6

Transmission Type

Synchromesh 6 Speed + 1 Reverse

GVW, kg

16200

Chassis Type

Domex 650 straight frame

Chassis Dimension, mm

230 x 76 x 6

Fuel Tank Capacity, L

425

Brakes

Dual Circuit 'S' Cam Full Air brakes

Tyres

10R20-16PR; 295/80R22.5-16PR

Suspension

Weveller / Semi-elliptic (Front), Weveller / Air (Optional) / Semi-elliptic (Rear)

Steering

Power steering

Battery

2x12 V, 150 Ah

Alternator

90 A

Application

Intercity, Route Permit, and Staff Applications

Specification

Details

Efficiency Feature

Cruise control

Efficiency Feature

Fuel Coaching

Efficiency Feature

Mbooster+

Safety Feature

Intelligent Engine Protection System (EPS)

Telematics Feature

Eicher Live telematics system

Driver Information Feature

Intelligent Driver Information System (IDIS 2.0)

Fuel System Feature

Corrosion-free HPDE fuel tank

Safety Feature

Engine exhaust brake

Brake Feature

Larger pneumatic brakes
