Eicher 6016 M LP Diesel – Eicher Trucks and Buses School Bus Chassis
Specifications
|
Specification |
Details |
|
Bus Model |
6016 M LP |
|
Wheelbase, mm |
5340 |
|
Overall length, mm |
9902 |
|
Overall width, mm |
2540 |
|
Overall height, mm |
2728 |
|
Ground clearance, mm |
245 |
|
Front overhang, mm |
1362 |
|
Rear overhang, mm |
3200 |
|
Turning circle diameter, m |
20.9 |
|
Engine make |
VEDX5 |
|
Displacement, cc |
5132 |
|
Power |
155 kW @ 2200 Rpm |
|
Torque |
825 Nm @ 1200-1600 Rpm |
|
Clutch diameter, mm |
395 |
|
Transmission make |
ET70S6 |
|
Transmission type |
Synchromesh 6 Speed + 1 Rev |
|
GVW, t |
16.2 |
|
Chassis type |
Domex 650 straight frame |
|
Chassis dimension, mm |
230 x 76 x 6 |
|
Fuel tank capacity, L |
250 |
|
Brakes |
Dual Circuit 'S' Cam Full Air brakes |
|
Tyres |
10R20-16PR |
|
Suspension |
Weveller-Front, Weveller-Rear |
|
Steering |
Power steering |
|
Battery |
2x12V, 150Ah |
|
Alternator |
90A |
|
DEF tank capacity, L |
33 |
|
Fuel Type |
Diesel |
|
Application |
School Buses |
Components & Features
|
Specification |
Details |
|
Efficiency Feature |
Cruise control |
|
Efficiency Feature |
Fuel Coaching |
|
Efficiency Feature |
Mbooster+ |
|
Safety Feature |
Intelligent Engine Protection System (EPS) |
|
Telematics Feature |
Eicher Live telematics system |
|
Driver Information Feature |
Intelligent Driver Information System (IDIS 2.0) |
|
Fuel System Feature |
Corrosion-free HPDE fuel tank |
|
Safety Feature |
Engine exhaust brake |
|
Brake Feature |
Larger pneumatic brakes |
