Specification

Details

Bus Model

6016 H LP

Wheelbase, mm

4200

Overall length, mm

8082

Overall width, mm

2540

Overall height, mm

2728

Ground clearance, mm

245

Front overhang, mm

1362

Rear overhang, mm

2520

Turning circle diameter, m

18.9

Engine make

VEDX5

Displacement, cc

5132

Power

155 kW @ 2200 Rpm

Torque

825 Nm @ 1200-1600 Rpm

Clutch diameter, mm

395

Transmission make

ET70S6

Transmission type

Synchromesh 6 Speed + 1 Rev

GVW, t

16.2

Chassis type

Domex 650 straight frame

Chassis dimension, mm

230 x 76 x 6

Fuel tank capacity, L

250

Brakes

Dual Circuit 'S' Cam Full Air brakes

Tyres

10R20-16PR

Suspension

Weveller-Front, Weveller-Rear

Steering

Power steering

Battery

2x12V, 150Ah

Alternator

90A

DEF tank capacity, L

33

Fuel Type

Diesel

Application

School Buses
