Eicher 280 PLUS 4WD – 4WD Agricultural Tractor by Eicher Tractors
Specifications
|
Specification |
Details |
|
Tractor Model |
Eicher 280 PLUS 4WD |
|
Vehicle Category |
4WD Tractor |
|
Overall Length |
2875 mm |
|
Overall Width |
1140 mm (Narrow - 965 mm) |
|
Overall Height |
1320 mm (At driver seat) |
|
Wheelbase |
1550 mm |
|
Total Weight |
1015 kg |
|
Fuel Type |
Diesel |
|
Application |
4WD Agricultural Tractor |
|
Fuel Tank Capacity |
23 L |
|
Max Speed |
23.55 kmph |
Frame & Drivetrain
|
Specification |
Details |
|
Engine Make / Type |
SIMPSON / Water cooled |
|
Cylinders |
2 |
|
Cubic Capacity |
1290 cc (1.29L) |
|
Fuel Injection Pump |
Inline |
|
Clutch Type |
Single |
|
Transmission Type |
Side shift, Partial constant mesh |
|
Number of Speeds |
9 Forward + 3 Reverse |
|
Power Range |
19.12 kW (26 hp) |
Suspension & Brakes
|
Specification |
Details |
|
Brake Type |
Oil immersed brakes |
|
Steering Type |
Power steering |
Wheels & Tyres
|
Specification |
Details |
|
Tyre Dimensions |
12.7 cm x 30.48 cm (5.0 x 12) Front, 20.32 cm x 45.72 cm (8 x 18) Rear (standard); 17.78 cm x 30.48 cm (180 / 85D12) Front, 21.08 cm x 50.80 cm (8.3 x 20) Rear (option) |
Components & Features
|
Specification |
Details |
|
PTO Type |
Live, Six splined shaft, Two-speed PTO |
|
PTO Speed (Standard) |
540 RPM @ 2450 ERPM, 540 RPM @ 1750 ERPM |
|
Lifting Capacity |
750 kgf |
|
Three Point Linkage & Controls |
Draft, position and response control, Links fitted with CAT-I (Combi Ball) |
|
Electricals |
12 V 65 Ah Battery |
|
Accessories |
Tipping trailer kit, Swinging draw bar, Drawbar, Hitch rails, Top link |
