2025 Conway GRV 4.0 SE Diamond – Gravel Bike

Images:

1

2

3

4

5

Specifications

Specification	Details
Model	GRV 4.0 SE Diamond
Vehicle Category	Gravel Bike
Application	Gravel riding, touring, commuting
Starting Price (2025)	€1,699.95
Color Options	Bronze Matt
Sizes	S (49 cm, 28"), M (51 cm, 28"), L (53 cm, 28"), XL (55 cm, 28")

Frame & Drivetrain

Specification	Details
Frame	Aluminium, Diamond
Fork	28" Carbon, Tapered 1 1/8" - 1.5", 300 mm shaft, Flat Mount
Crank	SRAM "Apex 1 Wide", 170 mm, 40T
Chain	SRAM "Apex", 12-speed, Flattop
Bottom Bracket	SRAM "DUB", BSA, 68 mm housing width, for Wide Axle
Shifters	SRAM "Apex", Hydraulic, 2 Piston, Flat Mount, 12-speed
Rear Derailleur	SRAM "Apex XPLR"

Components & Features

Specification	Details
Seating	SELLE ROYAL "SRX", Athletic, black
Wheels/Tyres	28" SCHWALBE "G-One Allround" Performance Line (front, 40-622, RaceGuard, Addix, TLE, folding, 67 TPI, E-25, black / bronze), SCHWALBE "G-One Allround" Performance Line (rear, 40-622, RaceGuard, Addix, TLE, folding, 67 TPI, E-25, black / bronze), RODI "Sniper 24" Rims, MACH 1 "PRO" Spokes, SRAM "PG-1231" 11-44T
Wheel Size	28"
Brakes	Hydraulic Disc Brakes, SRAM "Apex" (160 mm, front and rear)
Brake Levers	SRAM "Apex"
Handlebar	CONWAY "GRV Bar", 400 mm, Ø 31.8 mm, reach 70 mm, drop 125 mm, flare 6°, black
Stem	CONWAY "GRV A-Head", 1 1/8", 31.8 mm handlebar clamp, 80 mm long, angle 7°, black
Grips	VELO "2K", black
Headset	GLORY WHEEL IS42/28.6 / IS52/40
Saddle	SELLE ROYAL "SRX", Athletic, black
Seatpost	EASTON "EA50", Ø 27.2 mm, 350 mm long, 10 mm offset, black
Front Hub	FORMULA "RX512", 12 x 100 mm, 6-hole, 32 holes, thru axle, black
Rear Hub	SHIMANO "FH-TC500-HL", 12 x 142 mm, Center Lock, 11/12-speed HG, 32 hole, Thru Axle, black
Rims	RODI "Sniper 24", 24-622, 32 hole, disc brake, Tubeless Ready, black
Spokes	MACH 1 "PRO"
Exterior Features	CONWAY for GRV Aluminum Dropout
Weight	10.80 kg

* All the images are screenshots!
* Data has been taken from official website (Publicly Available)!
