2025 Commencal Supreme DH V5 Ride Frozen Brown – Downhill Bike
Specifications
|
Specification |
Details |
|
Model |
Supreme DH V5 Ride Frozen Brown |
|
Vehicle Category |
Downhill Bike |
|
Application |
Downhill racing, bike park |
|
Starting Price (2025) |
$5,400.00 |
|
Color Options |
Frozen Brown |
|
Sizes |
M (5'6" - 5'11"), L (5'10" - 6'3"), XL (6'2" - 6'11") |
Frame & Drivetrain
|
Specification |
Details |
|
Frame |
SUPREME DH V5, 220 mm travel, 29/27.5'', Alloy 6066, triple butted tubes, T4, T6 |
|
Fork |
ROCKSHOX Boxxer, 200 mm, 29", Charger RC damper, DebonAir, LSC, rebound, Boost (20 x 110 mm), 56 mm offset, 0 Token |
|
Rear Shock |
ROCKSHOX Super Deluxe Select R, 250 x 75 mm, R damper, DebonAir, rebound, Debonair, 1 token 0 Token neg. 3 Tokens pos. |
|
Crank |
TRUVATIV Descendant DH, 165 mm, DUB |
|
Chain |
KMC X11EL, Black |
|
Bottom Bracket |
SRAM DUB, Pressfit |
|
Shifters |
SRAM GX DH, 7 sp |
|
Rear Derailleur |
SRAM GX DH, 7 sp |
Components & Features
|
Specification |
Details |
|
Seating |
FIZIK Gravita Alpaca X5, 130 mm width, S-Alloy rails |
|
Wheels/Tyres |
Rear: 27.5" MAXXIS DHR II 27.5x2.40 WT, 3C MaxxGrip, DH casing, Tubeless Ready; Front: 29" MAXXIS Assegai 29x2.50 WT, 3C MaxxGrip, Double Down, Tubeless Ready; SPANK 359 Rims; SRAM PG-720 11-25t |
|
Wheel Size |
29" / 27.5" |
|
Brakes |
Hydraulic Disc Brakes, TRP DH-R Evo 4-piston (223 mm, front and rear) |
|
Brake Levers |
TRP DH-R Evo |
|
Handlebar |
RIDE ALPHA R27, 31.8 mm, 780 mm width on S/M/L, 800 mm on XL, 27 mm rise, Alloy 6061 |
|
Stem |
RIDE ALPHA DH 40, 40 mm extension, direct mount, 31.8 mm |
|
Grips |
ODI Elite Motion, Soft pro compound, single clamp, black |
|
Headset |
ACROS ZS56 / ZS56, Alloy cups, sealed bearings |
|
Saddle |
FIZIK Gravita Alpaca X5, 130 mm width, S-Alloy rails |
|
Seatpost |
RIDE ALPHA Super Light, 31.6 mm, 250 mm, Alloy 7075 |
|
Front Hub |
FORMULA DHL-93, 32h, sealed bearings, 20 x 110 mm Boost, black |
|
Rear Hub |
FORMULA DHG-157, 32h, sealed bearings, 12 x 157 mm, Shimano Hyperglide |
|
Rims |
SPANK 359, Rear: 27.5'', 30 mm inner width; Front: 29'', 30 mm inner width |
|
Spokes |
SAPIM Race, J-Bend, 2.0-1.8-2.0 mm, double butted, stainless, with Nylok, black |
|
Exterior Features |
Chainstay protector, seatstay protector, downtube protector, roller cover, frame mudguard |
|
Weight |
17.5 kg (S) |
