Specification

Details

Model

Meta V5 Essential Pure White

Vehicle Category

Enduro Bike

Application

Enduro, racing

Starting Price (2025)

$3,250.00

Color Options

Pure White

Sizes

M (5'6" - 5'11"), L (5'10" - 6'3")

Specification

Details

Frame

META V5, 150 mm travel, 29'', Alloy 6066, triple butted tubes, T4, T6

Fork

FOX 36 Performance, 160 mm, 29", Fit Grip damper, 3 positions, rebound, Boost (15 x 110 mm), 44 mm offset, 1 spacer

Rear Shock

FOX Float X Performance, 210 x 55 mm, 2-pos lever, rebound, LSC, 0.6 spacer

Crank

SHIMANO SLX, 170 mm, Boost

Chain

SHIMANO SLX, 12s

Bottom Bracket

SHIMANO BB71, Pressfit

Shifters

SHIMANO SLX, 12s

Rear Derailleur

SHIMANO SLX, 12s

Specification

Details

Seating

SDG Bel Air V3, 140 mm width, steel rails

Wheels/Tyres

29" MAXXIS DHR II (rear, 29x2.40 WT, EXO, Dual compound, Tubeless Ready), MAXXIS DHR II (front, 29x2.40 WT, EXO, 3C MaxxGrip, Tubeless Ready), DT SWISS E 532 Rims, SHIMANO SLX 10-51t

Wheel Size

29"

Brakes

Hydraulic Disc Brakes, SHIMANO SLX 4-piston (203 mm, front and rear)

Brake Levers

SHIMANO SLX, I-Spec EV compatible

Handlebar

RIDE ALPHA R20 760 on S, RIDE ALPHA R27 780 on M/L, RIDE ALPHA R27 800 on XL, 31.8 mm, 20 mm rise on S, 27 mm rise on M/L/XL, Alloy 6061

Stem

RIDE ALPHA 40, 40 mm extension, 31.8 mm

Grips

ODI Longneck, Soft compound, single clamp, black

Headset

ACROS ZS56 / ZS56, Alloy cups, sealed bearings

Saddle

SDG Bel Air V3, 140 mm width, steel rails

Seatpost

KS Rage-i, 34.9 mm, travel: 125 mm on S, 170 mm on M/L, 190 mm on XL, SouthPaw alloy remote

Front Hub

FORMULA DC-711, 32h, 15 x 110 mm, sealed bearings

Rear Hub

FORMULA MSL-148A, 32h, 12 x 148 mm, sealed bearings, Micro Spline

Rims

DT SWISS E 532, 29'', 30 mm inner width

Spokes

SAPIM Race, J-Bend, 2.0-1.8-2.0 mm, double butted, stainless, with Nylok, black

Exterior Features

Down tube protector, chainstay protector, seatstay protector, pick up pad, fork fender

Weight

15.8 kg (S)
