CFMOTO ZFORCE 800 Trail 2025 – 50-Inch Sport UTV
Specifications
|
Specification |
Details |
|
Engine Type |
V-Twin, 4-stroke, liquid-cooled, SOHC, 8-valve |
|
Displacement |
800 cc |
|
Power |
58 hp @ 7500 rpm |
|
Torque |
67.8 Nm (50 lb-ft) @ 5750 rpm |
|
Fuel System |
Electronic fuel injection (EFI), Bosch |
|
Fuel Capacity |
37 liters (9.8 gallons) |
|
Transmission |
CVTech Automatic P/R/N/H/L, CVTech IBC clutch |
|
Brakes |
Front/Rear: Hydraulic disc with parking brake |
|
Suspension |
Front/Rear: Double A-arm independent, 254 mm (10.0 in.) travel |
|
Wheel Size |
Front/Rear: 14-inch |
|
Tyres |
Front: 26 x 8-14; Rear: 26 x 9-14 (CST) |
|
Weight |
630 kg (1390 lbs, curb) |
|
Dimensions (LxWxH) |
3073 x 1270 x 1829 mm (121.0 x 50.0 x 72.0 in.) |
|
Wheelbase |
2286 mm (90.0 in.) |
|
Ground Clearance |
254 mm (10.0 in.) |
|
Towing Capacity |
680 kg (1500 lbs) |
|
Cargo Box Capacity |
100 kg (220 lbs) |
|
Price |
$13,099 (US, MSRP) (Year-2025) |
Frame & Drivetrain
|
Specification |
Details |
|
Chassis |
Steel frame |
|
Engine Type |
V-Twin, 4-stroke, liquid-cooled, SOHC, 8-valve |
|
Drivetrain |
Selectable 2WD/4WD, locking front differential, CVTech CVT |
Suspension & Brakes
|
Specification |
Details |
|
Front Suspension |
Double A-arm independent, 254 mm (10.0 in.) travel, spring preload adjustable |
|
Rear Suspension |
Double A-arm independent, 254 mm (10.0 in.) travel, adjustable rebound/compression |
|
Front Brake |
Hydraulic disc |
|
Rear Brake |
Hydraulic disc with parking brake |
|
Steering |
Variable-assist electronic power steering (EPS), tilt steering |
Wheels & Tyres
|
Specification |
Details |
|
Wheels |
14-inch aluminum alloy rims |
|
Tyres |
Front: 26 x 8-14; Rear: 26 x 9-14 (CST) |
|
Wheel Size |
Front/Rear: 14-inch |
Components & Features
|
Specification |
Details |
|
Seat |
Adjustable sport seats, 3-point safety belts |
|
Instrument Cluster |
5-inch LCD display, CFMOTO RideSync app integration |
|
Features |
RideVision LED headlights with DRL, LED taillights, 3500 lb winch, hard roof, half doors, stainless steel bumpers, side mirrors, 2-inch hitch receiver |
|
Safety Features |
3-point safety belts, full-length skid plate, A-arm skid plates, adjustable passenger grab bar, half doors |
Available Colors
|
Specification |
Details |
|
Colors |
Nebula Black, Desert Tan, Magma Red |
