CFMOTO CFORCE 520L 2025 – Two-Up Utility ATV
Specifications
|
Specification |
Details |
|
Engine Type |
Single-cylinder, 4-stroke, SOHC, liquid-cooled |
|
Displacement |
495 cc (30.2 cu in) |
|
Max Power |
34 hp @ 6750 rpm |
|
Max Torque |
41 Nm (30.2 lb-ft) @ 5250 rpm |
|
Fuel System |
Bosch electronic fuel injection (40 mm throttle body) |
|
Transmission |
CVTech Continuously Variable Transmission (CVT), High/Low/Neutral/Reverse/Park |
|
Drivetrain |
Switchable 2WD/4WD with front differential lock |
|
Curb Weight |
408 kg (899 lbs) |
|
Fuel Capacity |
17 liters (4.5 gallons) |
|
Towing Capacity |
802 kg (1768 lbs) braked, 260 kg (573 lbs) unbraked |
|
Ground Clearance |
270 mm (10.6 inches) |
|
Warranty |
2 years, parts and labor |
|
Price (US, 2025) |
$7,299 (~€6,840) (Year-2025) |
|
Price (UK, 2025) |
£6,999 (~€8,305) (Year-2025) |
|
Price (EU, 2025) |
€6,595(Year-2025) |
Frame & Chassis
|
Specification |
Details |
|
Frame |
High-strength steel, 10% lighter, 30% more rigid |
|
Dimensions (L x W x H) |
2235 x 1180 x 1390 mm (88.0 x 46.5 x 54.7 in) |
|
Wheelbase |
1480 mm (58.3 in) |
|
Minimum Turning Diameter |
7200 mm (23.6 ft) |
Suspension & Brakes
|
Specification |
Details |
|
Front Suspension |
Independent double A-arm, adjustable shocks, 250 mm travel |
|
Rear Suspension |
Independent double A-arm, adjustable shocks, 250 mm travel |
|
Brakes |
Hydraulic disc brakes, front and rear, with mechanical handbrake |
Wheels & Tyres
|
Specification |
Details |
|
Wheels |
12-inch alloy rims |
|
Tyres |
CST AT 25 x 8-12 front, 25 x 10-12 rear, 6-ply |
Components & Features
|
Specification |
Details |
|
Lighting |
RIDE VISION LED headlights, taillights, running lights |
|
Instrument Cluster |
3.5-inch LCD digital gauge, full-screen backlight |
|
Seating |
Two-up seating, 40% thicker foam, wider backrest, passenger handles, extended footrests |
|
Features |
Electronic Power Steering (EPS), 1360 kg (3000 lbs) winch, tow bar, 7-pin trailer hookup, steel racks (34 kg front, 60 kg rear), 12V socket, 2 USB ports, active engine braking, lockable gear lever, CF-connect quick-release system, handguards, 2.5L rear storage, arched front A-arms, homologated for road use (two people), Euro 5 compliant |
Available Colors
|
Specification |
Details |
|
Colors (2025) |
Force Red, Tundra Grey, Nebula Black, Camouflage (+€100 in some markets) |
