Case IH Optum 270 CVXDrive – 4WD High-Performance Tractor
Specifications
|
Specification |
Details |
|
Tractor Model |
Optum 270 CVXDrive |
|
Vehicle Category |
High-Performance Tractor |
|
Fuel Type |
Diesel |
|
Application |
Precision Farming, Large-Scale Arable Farming |
Frame & Drivetrain
|
Specification |
Details |
|
Engine |
FPT, 6 Cylinders, 6728 cm³, Common Rail Diesel, eVGT Turbocharger, Hi-eSCR2, Stage V |
|
Maximum Horsepower |
288 HP (212 kW) @ 1800 RPM |
|
Rated Horsepower |
271 HP (199 kW) @ 2100 RPM |
|
Maximum Torque |
1194 Nm @ 1400 RPM |
|
Torque Rise |
32% |
|
Transmission Type |
CVXDrive Continuously Variable, 40/50 kph ECO, Powershuttle |
Suspension & Brakes
|
Specification |
Details |
|
Frame |
270 kg Engine Block Frame |
|
Suspension |
Mechanical Cab Suspension, Optional Active Front Axle Suspension (105 mm Travel) |
|
Braking System |
Hydraulically Operated Multiple Wet Disc Brake, Self-Adjusting, Optional Advanced Trailer Brake System, Retarder (149 kW) |
Wheels & Tyres
|
Specification |
Details |
|
Standard Tyres (Front/Rear) |
540/65 R28 / 650/85 R38 |
|
Largest Tyres (Front/Rear) |
650/60 R34, IF 620/75 R30, IF 650/60 R34 / 710/75 R42, 900/60 R42, IF 710/75 R42, IF 900/60 R42 |
|
Track Setting (Front/Rear) |
1858-2258 mm / 1840-2374 mm (Bar Axle) |
Components & Features
|
Specification |
Details |
|
PTO Type |
Electro-Hydraulic, Auto PTO, 540/540E/1000/1000E (1871/1598/1853/1583 RPM), Optional Front PTO 1000/1000E (1886/1585 RPM) |
|
Hydraulic System |
Variable Displacement, Pressure Flow Compensated, 165 l/min (Standard), 220 l/min (Optional), 90 L Oil Volume, Up to 5 Rear Remote Valves, Up to 3 Mid-Mount Valves, Power Beyond (Professional Edition) |
|
Rear Lift |
Electronic Hitch Control, Cushion Ride Control, Cat III N/IV N, Max Lift Capacity 11,058 kg, OECD Lift Capacity 10,299 kg @ 610 mm |
|
Front Lift |
Optional, Max Lift Capacity 6,016 kg, OECD Lift Capacity 4,487 kg @ 610 mm |
|
Cab Options |
Standard (No Suspension, Fabric Seat), Deluxe Fabric/Leather (Mechanical Suspension, Active Seat), Active Leather (Premium Seat, Ventilation, Carpet), AFS Pro 1200 Monitor, HMC II, ISOBUS II/III (Optional) |
|
Fuel Tank Capacity |
630 L (Diesel), 96 L (AdBlue) |
|
Weight |
Approx. 11,530 kg, Permissible Total Weight 16,800 kg |
|
Wheelbase |
2,995 mm |
|
Length |
5,825 mm |
|
Height |
3,457 mm |
|
Width |
2,536-2,993 mm |
