Specification

Details

Model

Trail 6

Vehicle Category

Mountain Bike

Application

Low-impact trails, gravel roads, leisurely rides

Starting Price (2025)

$625.00 USD

Color Options

Smoke Black

Specification

Details

Frame

SmartForm C3 Alloy, SAVE, 1-1/8" headtube, post mount disc, StraightShot internal cable routing, dropper post compatible, BSA-73, rear rack mounts, KickFlip hidden 18mm 2-bolt kickstand mount

Fork

SR Suntour XCT 30, 100mm, coil, 42mm offset (27.5") 46mm offset (29")

Drivetrain Compatibility

Shimano Alivio/Acera, 2x9-speed

Dropouts

Quick Release (F), Quick Release (R)

Bottom Bracket

Sealed cartridge bearing, square taper

Crank

Prowheel, 36/22

Chain

KMC X9, 9-speed

Rear Derailleur

Shimano Acera

Front Derailleur

Shimano Altus, 34.9 clamp

Shifters

Shimano Alivio, 9-speed

Cassette

Shimano HG200, 11-36, 9-speed

Specification

Details

Seating

1 passenger (Cannondale Stage 3)

Cargo Capacity

Rear rack mounts, KickFlip hidden 18mm 2-bolt kickstand mount

Wheels/Tyres

(F) WTB Ranger Comp, 27.5x2.25" (XS, SM) / 29x2.25" (MD, LG, XL), DNA Compound / (R) WTB Ranger Comp, 27.5x2.25" (XS, SM) / 29x2.25" (MD, LG, XL), DNA Compound

Wheel Size

27.5" (XS, SM) / 29" (MD, LG, XL)

Brakes

Tektro M275 hydraulic disc, 160/160mm rotors

Brake Levers

Tektro hydraulic disc

Handlebar

Cannondale Riser, 6061 Alloy, 25mm rise, 8° sweep, 6° rise, 720mm

Stem

6061 Alloy, 31.8, 7°

Headset

Semi-Integrated, 1-1/8"

Saddle

Cannondale Stage 3

Seatpost

Cannondale 3, 6061 Alloy, 31.6x350mm (XS-SM), 400mm (MD-XL)

Seatpost Clamp

Integrated

Grips

Cannondale Dual-Density

Front Hub

Shimano HB-TX505, QR

Rear Hub

Shimano FH-TX505, QR

Rims

WTB SX19, 32h

Spokes

Stainless Steel, 14g

Pedals

Cannondale Platform

Exterior Features

Rear rack mounts, KickFlip hidden 18mm 2-bolt kickstand mount
