2025 Cannondale SuperX 3 – Gravel Bike
Specifications
|
Specification |
Details |
|
Model |
SuperX 3 |
|
Vehicle Category |
Gravel Bike |
|
Application |
Gravel racing |
|
Starting Price (2025) |
$4,599.00 USD |
|
Color Options |
Raw |
Frame & Drivetrain
|
Specification |
Details |
|
Frame |
SuperX Carbon, Proportional Response construction, internal cable routing, 12x142mm thru-axle, UDH BSA 68mm threaded BB, flat mount disc, integrated seatpost binder |
|
Fork |
SuperX Carbon, integrated crown race, 12x100mm thru-axle, flat mount disc, internal routing, 1-1/8" to 1-1/2" Delta steerer, 55mm offset |
|
Drivetrain Compatibility |
Shimano GRX 820, 2x12-speed |
|
Dropouts |
12x142mm thru-axle (rear), 12x100mm thru-axle (front) |
|
Bottom Bracket |
Shimano BSA 68 |
|
Crank |
Shimano RX 820, 48/32 |
|
Chain |
Shimano M8100, 12-speed |
|
Rear Derailleur |
Shimano GRX 820, Shadow RD+ |
|
Front Derailleur |
Shimano GRX 820, braze-on |
|
Shifters |
Shimano GRX 820, 12-speed |
|
Cassette |
Shimano 105 7100, 11-36, 12-speed |
Components & Features
|
Specification |
Details |
|
Seating |
1 passenger (Prologo Dimension AGX STN) |
|
Wheels/Tyres |
Vittoria Terreno T50, 700x40c, tubeless ready |
|
Wheel Size |
700c |
|
Brakes |
Shimano GRX 820, 160/160mm CL800 rotors |
|
Brake Levers |
Shimano GRX RX820 hydraulic disc |
|
Handlebar |
Cannondale C2, 7050 Alloy, Compact |
|
Stem |
Cannondale C1 Conceal, Alloy, 31.8, -6° |
|
Headset |
Integrated, 1-1/8" - 1.5" |
|
Saddle |
Prologo Dimension AGX STN |
|
Seatpost |
Cannondale C1 Aero 27 Carbon, SmartSense compatible, 0mm offset (46cm), 20mm offset (51-61cm) |
|
Seatpost Clamp |
Integrated |
|
Grips |
Cannondale Bar Tape, 3.5mm |
|
Front Hub |
DT Swiss 370, 12x100mm centerlock |
|
Rear Hub |
DT Swiss 370, 12x142mm centerlock |
|
Rims |
DT Swiss G1800 Spline, 24mm inner width, 25mm depth, 24h, tubeless ready |
|
Spokes |
DT Swiss Aero Comp |
|
Exterior Features |
Cannondale Wheel Sensor, Tubeless valves |
