2025 Cannondale Moterra SL 1 – Electric Mountain Bike
Specifications
|
Specification |
Details |
|
Model |
Moterra SL 1 |
|
Vehicle Category |
Electric Mountain Bike |
|
Application |
Trail riding, technical climbs, descents |
|
Starting Price (2025) |
$8,750.00 USD |
|
Color Options |
Tungsten Blue, Raw |
Frame & Drivetrain
|
Specification |
Details |
|
Frame |
Moterra SL Carbon, 150mm travel, Proportional Response Tuned Suspension, FlexPivot Chainstay, direct mount internal battery, engineered plastic skid plate, 55mm chainline, internal cable routing, 29” FlipChip, 148x12mm Maxle thru-axle, UDH hanger, 200mm native post mount brake, angle adjust headset |
|
Fork |
Fox Float Factory 36, 160mm travel, Grip X2 Damper, Kashima coating, 15x110mm Kabolt thru-axle, tapered steerer, 44mm offset |
|
Rear Shock |
Fox Float X Factory, 2 pos adj, EVOL LV, 210x55mm |
|
Drivetrain Compatibility |
SRAM XO Eagle AXS, T-Type, 12-speed |
|
Dropouts |
148x12mm Maxle thru-axle |
|
Bottom Bracket |
SRAM DUB, integrated |
|
Crank |
e*thirteen e*spec Race Carbon, 160mm (S/M), 165mm (L/XL), 34T |
|
Chain |
SRAM XO Eagle, T-Type, 12-speed |
|
Rear Derailleur |
SRAM XO Eagle AXS, T-Type |
|
Shifters |
SRAM AXS POD Controller |
|
Cassette |
SRAM XO Eagle, 10-52, T-Type, 12-speed |
Components & Features
|
Specification |
Details |
|
Seating |
1 passenger (Fizik Terra Aidon X3, Mobius Kium alloy rail) |
|
Fuel Type |
Electric |
|
Wheels/Tyres |
(F) Maxxis DHF, 29x2.5", 3C, EXO+, tubeless ready / (R) Maxxis Dissector, 27.5x2.4", 3C, EXO+, tubeless ready |
|
Wheel Size |
29" (F) / 27.5" (R) |
|
Brakes |
Magura MT7 4-piston hydraulic disc, 203/203mm Storm HC 6-bolt rotors |
|
Brake Levers |
Magura MT7 HCW hydraulic disc |
|
Handlebar |
HollowGram SAVE riser bar, Carbon, 35mm clamp, 30mm rise, 8° sweep, 5° rise, 780mm |
|
Stem |
Cannondale 1, 7075 Alloy, 1-1/8", 35mm, 0° |
|
Headset |
Acros Adjustable Angle (1.2°) |
|
Saddle |
Fizik Terra Aidon X3, Mobius Kium alloy rail |
|
Seatpost |
OneUp V3, internal routing, 31.6, 180mm (S), 210mm (M/L), 240mm (XL) |
|
Seatpost Clamp |
Integrated |
|
Grips |
Cannondale TaperRidge |
|
Front Hub |
DT Swiss 350, 15x110mm |
|
Rear Hub |
DT Swiss 350 Ratchet System 36 SL, 12x148mm |
|
Rims |
DT Swiss XM 1700 Spline, 30mm inner width, TC tubeless ready |
|
Spokes |
DT Swiss Competition, straight-pull |
|
Exterior Features |
Tubeless valves, SRAM AXS charger |
|
Drive Unit |
Shimano EP801, 85Nm, Custom Tuned, Eco, Trail 1, Trail 2, Boost Modes |
|
Battery |
Custom, integrated, direct mount, 601Wh |
|
Charger |
Custom 4A |
|
Display |
Shimano SC-EM800 Cycle Computer, Bluetooth LE Compatible |
|
Range |
Up to 100 km (62 miles) |
|
Certifications |
UL 2849 |
