Specification

Details

Model

Compact Neo

Vehicle Category

Electric Bike

Application

City cycling, commuting, leisure

Starting Price (2025)

$1,900.00 USD

Color Options

Smoke Black

Specification

Details

Frame

Compact Neo, SmartForm C2 Alloy, hidden downtube battery, 135x9mm, BSA 73, post mount disc

Fork

Compact Neo SmartForm C2 Alloy, 1-1/8" steerer, post mount disc, 100x9mm

Drivetrain Compatibility

1x8 speed

Dropouts

Quick Release (front 100x9mm, rear 135x9mm)

Bottom Bracket

Hyena torque sensor

Crankset

Samox, 48T

Chain

KMC X8, 8-Speed

Rear Derailleur

microSHIFT M26S Short-Cage

Shifter

microSHIFT 39-8R Thumb-Tap, 8-speed

Cassette

Sunrace, 11-34, 8-Speed

Specification

Details

Seating

1 passenger (Cannondale Treadwell, 170mm, steel rails)

Fuel Type

Electric-assisted, human-powered

Cargo Capacity

25 kg (55 lbs, rear rack)

Wheels/Tyres

Kenda K-Rad, 20x2.35"

Wheel Size

20" in

Brakes

Tektro HD-R280 hydraulic disc, 160/160mm rotors

Brake Levers

Tektro

Handlebar

Cannondale Cruise Control riser, 6061 Alloy, 31.8mm, 15° back, 740mm

Stem

TranzX Folding Stem

Headset

Semi-Integrated, 1-1/8"

Saddle

Cannondale Treadwell, 170mm, steel rails

Seatpost

Cannondale 4, 6061 Alloy, 31.6x540mm

Seatpost Clamp

Alloy, 31.8mm

Grips

Cannondale Comfort

Front Hub

Formula DC-1420, 100mm QR

Rear Hub

Hyena 250W Rear Hub Motor MRC-250

Rims

Cannondale, lightweight alloy, 20", 32h Front / 36h Rear

Spokes

(F) Stainless Steel, 14g / (R) 13g

Pedals

Folding, alloy

Interior Features

Hidden downtube battery, folding stem, folding pedals, Cannondale Wheel Sensor

Exterior Features

Herrmans H-Black MR4 front light, Herrmans H-Trace rear light, rear rack (25kg/55lbs), fenders

Weight

18 kg (40 lb)

Drive Unit

Hyena MRC-250, 250W

Battery

Hyena, 250Wh

Charger

2A

Display

Hyena HMI LED

Range

Up to 75 km
