2026 Bianchi T-Tronik X 9.1 – E-Bike
Specifications
|
Specification |
Details |
|
Model |
T-Tronik X 9.1 |
|
Vehicle Category |
E-Bike |
|
Application |
Sport trail riding |
|
Starting Price (2025) |
€3,690 |
|
Color Options |
Dark Celeste metallic/Celeste metallic [Full Matt] |
|
Sizes |
SM, MD, LG, XL |
Frame & Drivetrain
|
Specification |
Details |
|
Frame |
Bianchi T-Tronik X, aluminium, 12x148 mm rear thru axle, Post mount 180 disc brake type, Front travel 120 mm, Internal cable routing in steerer, 800 Wh battery compatible |
|
Fork |
Suntour XCR34X, Air, 120 mm travel, Steerer tube 1,5" tapered, 34 mm stanchions, 15x110 Boost axle, Rotor: minimum 180 mm, maximum 203 mm |
|
Crank |
FSA CK-320/IS, Aluminium DieCast, Crank length: 170 mm |
|
Chain |
KMC e10S EPT, Anti-Rust |
|
Bottom Bracket |
Not specified |
|
Shifters |
Shimano Deore SL-M4100, Rapidfire Plus |
|
Rear Derailleur |
Shimano Deore, RD-M4120, 10sp, Shadow design |
Components & Features
|
Specification |
Details |
|
Seating |
Velomann Gnd Full-fit Start Up, Carbon-steel rail, 262 mm x 145 mm |
|
Fuel Type |
Electric (Bosch Powertube 800 Wh) |
|
Wheels/Tyres |
Velomann 622x30, 32 hole, Front hub: Shimano TC500 Thru axle, Rear hub: Shimano TC500 Thru axle, Obor Mike Bear, 29"x2,35", 60 TPI |
|
Wheel Size |
29" |
|
Brakes |
Sram Guide T, 4 piston, Sram Centerline, 200 mm front, 180 mm rear |
|
Brake Levers |
Sram Guide T, included in the brake |
|
Handlebar |
Velomann Aluminium, Rise 15 mm, Barbore 31.8 mm, Width 740 mm |
|
Stem |
Velomann Viper0, alloy, Diameter 28.6 mm, Barbore 31,8 mm, Size: 60 mm |
|
Headset |
Acros Integrated Cable Routing |
|
Saddle |
Velomann Gnd Full-fit Start Up, Carbon-steel rail, 262 mm x 145 mm |
|
Seatpost |
Velomann AL2014, Diameter: 31,6 mm, Seatback: 0 mm (SM); Dropper, travel 125 mm (MD-LG); Dropper, travel 150 mm (XL) |
|
Grips |
Herrmans Luna lock 130 mm |
|
Front Hub |
Shimano TC500 Thru axle |
|
Rear Hub |
Shimano TC500 Thru axle |
|
Rims |
Velomann 622x30, 32 hole |
|
Spokes |
32 hole |
