2022 Bianchi E-Spillo City Step Thru – E-Bike
Specifications
|
Specification |
Details |
|
Model |
E-Spillo City Step Thru |
|
Vehicle Category |
E-Bike |
|
Application |
Urban commuting |
|
Starting Price (2025) |
€1,199 |
|
Color Options |
Gun Barrel Grey/Black Full Glossy |
|
Sizes |
45cm |
Frame & Drivetrain
|
Specification |
Details |
|
Frame |
E-Spillo City Step Thru Frame Aluminium, O.L.D.139mm for rear hub motor unit |
|
Fork |
Bianchi Steel, V-Brake |
|
Crank |
Prowheel PRA-11C 38T, crank length: 170mm |
|
Chain |
Kmc Z8.1 8sp |
|
Bottom Bracket |
Axle length: 124mm, w/speed sensor |
|
Shifters |
Shimano Altus 8sp |
|
Rear Derailleur |
Shimano Altus 8sp |
Components & Features
|
Specification |
Details |
|
Seating |
Selle Royal Aurorae UNISEX |
|
Fuel Type |
Electric (Phylion SF-03 317 Wh) |
|
Cargo Capacity |
AVS CLASSIC CARRIER FOR PHILION BATTERY |
|
Wheels/Tyres |
Front hub: Formula FM-21, Rear hub: EGoing Rear hub motor unit, Duramax Regular H-480, Tire sport Pergo 40-622 27TPI |
|
Wheel Size |
28" |
|
Brakes |
V-Brake Alloy |
|
Brake Levers |
Aluminium, 4 fingers |
|
Handlebar |
HB CITY steel diam.25.4mm, 610mm/44°/rise 66mm |
|
Stem |
STQ ALsbbk 25,4/85 180mm 4BOLT MTSD-367N-5 black |
|
Headset |
VP-MH305C |
|
Saddle |
Selle Royal Aurorae UNISEX |
|
Seatpost |
Aluminium diam.27.2mm, length:350mm |
|
Grips |
Herrmans Ergo TPE 120 mm |
|
Front Hub |
Formula FM-21 |
|
Rear Hub |
EGoing Rear hub motor unit |
|
Pedals |
Included |
|
Exterior Features |
Steel mudguards, Atranvelo KS Rex Atran 235 kickstand, AVS CLASSIC CARRIER FOR PHILION BATTERY, Breeze Evo Classic 15 Lux front light, rear light integrated in the battery |
