Specification

Details

Tractor Model

Valiant 60 AR Micro (4WD)

Vehicle Category

Specialized Tractor

Fuel Type

Diesel

Application

Orchards, Vineyards, Greenhouse Crops, Nurseries, Municipality Activities

Specification

Details

Engine

Kohler KDI 1903 TCA, 3 Cylinders, 1861 cm³, Turbo Intercooler, Common Rail Direct Injection, Stage V

Maximum Horsepower

49 HP (36 kW) @ 2600 RPM

Maximum Torque

190 Nm @ 1500 RPM

Transmission Type

Synchronised Gearbox, 12 Forward + 12 Reverse with Synchronised Reverser

Clutch

Multidisc in Oil Bath

Specification

Details

Frame

Swinging Integral Chassis (±15°), OS-FRAME with Central Articulation

Braking System

Multidisc in Oil Bath with Mechanical Control, Acting on Rear Wheels

Differential Lock

Front and Rear with Simultaneous Locking and Electro-Hydraulic Control

Specification

Details

Tyre Size (Front/Rear Combinations)

8.25-16 / 7.00-18, 210/95R18

Specification

Details

PTO Type

Rear, Independent from Gearbox, Synchronised with Forwarding Speed, Negative Safety Hydraulic Brake, Multidisc in Oil Bath Clutch with Electro-Hydraulic Control, 540 RPM

Hydraulic System

Dual Circuit with Independent Pumps, Flow to Power Steering 17.5 l/min, Flow to Lift and Control Valves 23 l/min, Maximum Pressure 180 bar

Rear 3-Point Hitch

Category 1, Standard Raising/Lowering with Two External Cylinders, Optional Position and Draft Control, Normal Couplings Cat. 1 or Quick-Couplings Cat. 1, L-Shaped, Arms Adjustable in Length and Hooks Adjustable in Width, Hydraulically Controlled Upper Link and Tie Rod Link Arm, Ball Joint Lifting Capacity 1200 kg

Steering

Hydrostatic Steering Acting on Central Joint, Flow Deviator for Steering Unit

Electrical System

Battery 80 Ah / 12 V, Alternator 95 A, Standard Equipment Street Light and Indicator System, Single-Pole Dashboard Socket, Rear 7-Pin Socket

Weight

1590 kg (Roll-Bar)

Ground Clearance

253-279 mm

Wheelbase

1340 mm

Width

950-1322 mm
