Başak Tractor 5115 – 4WD Field Tractor for Heavy Duty Agricultural Work
Specifications
|
Specification |
Details |
|
Tractor Model |
5115 (4WD) |
|
Vehicle Category |
Field Tractor |
|
Fuel Type |
Diesel |
|
Application |
Agricultural Field Work |
Frame & Drivetrain
|
Specification |
Details |
|
Engine |
Deutz TCD 3.6, 4 Cylinders, 3621 cm³, Turbo-Intercooler, Stage V |
|
Maximum Horsepower |
116 HP (86 kW) @ 2000 RPM |
|
Maximum Torque |
476 Nm @ 1600 RPM |
|
Transmission Type |
Mechanical Shuttle, 24 Forward + 24 Reverse, Power Hi-Lo (2 Stages) |
Suspension & Brakes
|
Specification |
Details |
|
Frame |
4WD Chassis |
|
Braking System |
Multi-Disc Oil-Immersed Brakes, Hydraulic Control for Service Brake, Mechanical Control for Parking Brake, Standard Four-Wheel Braking |
|
Differential Lock |
Front: Limited Slip, Rear: Electro-Hydraulic |
Wheels & Tyres
|
Specification |
Details |
|
Tyre Size (Standard Front/Rear) |
340/85R24 / 420/85R34 |
|
Tyre Size (Optional Front/Rear) |
340/85R24 / 480/70R34, 380/85R24 / 380/85R38, 380/70R28 / 480/70R38 |
Components & Features
|
Specification |
Details |
|
PTO Type |
Independent 2-Speed, 540/540E or 540/1000 RPM (Optional) |
|
Front PTO |
Optional, 1000 RPM, 6-Spline Multi-Disc Dry Clutch |
|
Hydraulic System |
Electronic Control, 70 l/min Pump Flow, 200 bar Pump Pressure, 8/4 or 6/3 Hydraulic Valve Outputs, 4500 kg Lifting Capacity, Standard Fender-Mounted Hydraulic Control, Electronic Auto-Lift |
|
Front Hitch |
Optional, 2200 kg Capacity, 2/1 Hydraulic Outputs |
|
Steering |
Electro-Hydraulic |
|
Weight |
4960-5340 kg (10935-11773 lb, Without Additional Weights) |
|
Ground Clearance |
360-510 mm (14.2-20.1 in) |
|
Fuel Tank Capacity |
120 l (31.7 gal) + 20 l (5.3 gal) AdBlue |
|
Wheelbase |
2500 mm (98.4 in) |
|
Width |
1610-2490 mm (63.4-98.0 in) |
|
Accessories |
Engine Power Management (RPM Lock Mode), Battery Isolator, Hydraulic Mid-Mount Arm, Air Compressor, Ledbar, Optional Rear-View Camera and Display |
