Başak Tractor 5120 T4 – 4WD Field Tractor for Efficient Farming
Specifications
|
Specification |
Details |
|
Tractor Model |
5120 T4 (4WD) |
|
Vehicle Category |
Field Tractor |
|
Fuel Type |
Diesel |
|
Application |
Field and Transport Work |
Frame & Drivetrain
|
Specification |
Details |
|
Engine |
Deutz TCD 3.6, 4 Cylinders, 3621 cc, Stage V, Turbo-Intercooler, Common Rail, Pre-Cleaner Air Filter |
|
Power |
85.4 kW / 116 hp (Nominal) @ 2200 rpm, 90 kW / 122 hp (Maximum) @ 2200 rpm |
|
Torque Max |
480 Nm @ 1600 rpm |
|
Transmission |
ZF, 32 forward + 32 reverse gears, Standard Power-Shuttle, 4-Stage Auto PowerShift, Electro-hydraulic Four-Wheel Drive Control |
Suspension & Brakes
|
Specification |
Details |
|
Differential Lock |
Front: Limited Slip (Automatic), Rear: Electro-hydraulic |
|
Brakes |
Oil-immersed Multi-disc Brake, Hydraulic Controlled |
|
Parking Brake |
Mechanic Controlled |
|
Trailer Braking |
Standard Trailer Air Braking Valve |
Wheels & Tyres
|
Specification |
Details |
|
Tyres |
Option 1: Front 380/70R28, Rear 420/85R38; Option 2: Front 380/70R28, Rear 480/70R38; Option 3: Front 440/65R28, Rear 540/65R38 |
|
Track Width Tyres |
Front: 1632–1974 mm, Rear: 1810–2022 mm |
Components & Features
|
Specification |
Details |
|
Power Take-Off |
Independent 4 Speed PTO, Electro-hydraulic Control, 540/540E/1000/1000E rpm, Synchronized to Wheel Speed |
|
Hydraulic System |
Electronic Control, 6/4 (16/3 Optional) Hydraulic Valve Outputs, Maximum Pump Flow 100 l/min at 200 bar, Maximum Lifting Capacity 5500 kg, Standard Mudguard Hydraulic Control, Electronic Auto-Lift |
|
Towing Device |
Height adjustable rear tow hook, Front tow hook, Trailer Air Braking Valve |
|
Platform |
Cabin with Air Conditioner, Radio, Passenger Seat, Digital Dashboard, 4-Stage Adjustable Steering Wheel, Hydraulic Mid-arm, Air Compressor, Battery Disconnect Switch, Front Loader, Motor Speed Stabilization Module, Over Drive Motor, Rear View Camera and Screen (Optional) |
|
Weight |
5480–5880 kg (without additional weights) |
|
Tank Capacity |
Fuel: 200 litres, AdBlue: 20 litres |
|
Additional Weights |
Front: 12 x 40 kg + 70 kg, Rear: 4 x 45 kg |
|
Front Lift |
Optional, Capacity 2200 kg, 2 Hydraulic Outputs |
|
Front PTO |
Optional, 6 Splines, Multi-disc Dry Clutch, 1000 rpm |
