Başak Tractor 2055 T4 – 4WD Compact Tractor for Precision Farming

Images:

1

2

Specifications

Specification	Details
Tractor Model	2055 T4 (4WD)
Vehicle Category	Compact Tractor
Fuel Type	Diesel
Application	Garden, Vineyard, Small-Scale Field Work

Frame & Drivetrain

Specification	Details
Engine	ITL 3100 FLT, 3 Cylinders, 2780 cc, Stage 3A, Turbo/Intercooler, Water Cooled
Power	43 kW / 58 hp @ 2100 rpm
Torque Max	230 Nm @ 1300 rpm
Transmission	Mechanic Synchronized, Mechanic Synchronized Shuttle, 8 forward + 8 reverse gears, Electro-hydraulic Four-Wheel Drive Control
Transmission Clutch	Double Disc Dry Type
Drive Disengagement	Electro-hydraulic

Suspension & Brakes

Specification	Details
Differential Lock	Front: Limited Slip, Rear: Mechanic Controlled
Brakes	Oil-immersed Disc Brake, Mechanic Controlled
Parking Brake	Mechanic Controlled

Wheels & Tyres

Specification	Details
Tyres	Option 1: Front 280/70R18, Rear 14.9-28; Option 2: Front 280/70R18, Rear 380/85R28
Track Width Tyres	Front: 1390 mm, Rear: 1380 mm

Components & Features

Specification	Details
Power Take-Off	Independent Double Speed, Electro-hydraulic PTO Clutch, 540 rpm (1953 engine rpm), 540E rpm (1506 engine rpm), Synchronized to Wheel Speed
Hydraulic System	Mechanic Controlled, Position, Draft, Sensitivity Functions, 4/2 Hydraulic Valve Outputs, Lifting Capacity 2700 kg
Towing Device	Height adjustable rear tow hook, Front tow hook
Platform	Open platform with roll bar
Weight	2860 kg (without additional weights)
Tank Capacity	65 litres
Additional Weights	Front: 4 x 30 kg + 50 kg, Rear: 2 x 45 kg

* All the images are screenshots!
* Data has been taken from official website (Publicly Available)!
