Ashok Leyland Titan Double Decker 2025 – High-Capacity Urban Bus
Specifications
|
Specification |
Details |
|
Engine |
H-series 6-cylinder, turbocharged, BS-VI diesel with CRS and iEGR |
|
Power |
197 hp (147 kW) @ 2500 rpm |
|
Torque |
700 Nm @ 1200–1800 rpm |
|
Transmission |
6-speed synchromesh manual |
|
Drivetrain |
Rear-Wheel Drive (4x2) |
|
Brakes |
Dual-circuit full air brakes with ABS |
|
Suspension |
Front: Shackle-ended semi-elliptical leaf springs with shock absorbers; Rear: Air suspension with 4 bellows |
|
Wheel Size |
295/80R22.5-16PR |
|
Tyres |
295/80R22.5-16PR (tubeless radial) |
|
Weight |
18000 kg (GVW); ~7500 kg (kerb, chassis only) |
|
Dimensions (LxWxH) |
~9500 x 2490 x 4200 mm (fully built, varies with body) |
|
Wheelbase |
~4900 mm |
|
Ground Clearance |
~250 mm (unladen, chassis) |
|
Fuel Tank Capacity |
239 L |
|
Mileage |
~3–5 km/L (real-world, varies with load and body) |
|
Price (Ex-Showroom, Delhi) |
₹65.00–85.00 Lakh (fully built, estimated) (Year-2025) |
|
Price (On-Road, Delhi) |
₹75.00–95.00 Lakh (estimated) (Year-2025) |
|
Seating Capacity |
65–85 (3x2 or 2x2 layouts, varies with configuration) |
Frame & Drivetrain
|
Specification |
Details |
|
Chassis |
Ladder-type with cross members, high-strength steel |
|
Engine Type |
H-series 6-cylinder, turbocharged, front-mounted |
|
Clutch |
Single dry plate, hydraulic actuation |
|
Gearbox |
6-speed synchromesh manual |
Suspension & Brakes
|
Specification |
Details |
|
Front Suspension |
Shackle-ended semi-elliptical leaf springs with telescopic shock absorbers |
|
Rear Suspension |
Air suspension with 4 bellows and shock absorbers |
|
Front Brake |
Air-actuated drum brakes |
|
Rear Brake |
Air-actuated drum brakes |
Wheels & Tyres
|
Specification |
Details |
|
Wheels |
10-stud steel wheels |
|
Tyres |
295/80R22.5-16PR (tubeless radial) |
|
Wheel Size |
295/80R22.5-16PR |
Components & Features
|
Specification |
Details |
|
Seat |
65–85 seats, 3x2 or 2x2 layouts, high-back seats, optional reclining |
|
Handlebar |
Power steering, adjustable tilt |
|
Instrument Cluster |
Analog with digital trip meter, speedometer, tachometer, fuel gauge |
|
Features |
Dual doors, optional AC, LED destination boards, CCTV, low-floor design, passenger handrails |
|
Safety Features |
ABS, seat belts, fire-retardant interiors, emergency exits, panic buttons, CCTV |
Available Colors
|
Specification |
Details |
|
Colors |
Customizable per body builder (e.g., White, Red, Blue, Green) |
