Antonio Carraro TTR 7600 Infinity – 4WD Utility Tractor for Hillside Farming
Specifications
|
Specification |
Details |
|
Tractor Model |
TTR 7600 Infinity (4WD) |
|
Vehicle Category |
Utility Tractor |
|
Fuel Type |
Diesel |
|
Application |
Mountain Pastures, Hillside Cultivations, Embankments, Urban Green Areas, Sports Grounds |
Frame & Drivetrain
|
Specification |
Details |
|
Engine |
Kohler, 4 Cylinders, 16 Valves, 2482 cm³, Common Rail Direct Injection, Turbo with Intercooler, Stage V |
|
Maximum Horsepower |
75 HP (55.4 kW) @ 2300 RPM |
|
Maximum Torque |
310 Nm @ 1500 RPM |
|
Transmission Type |
Hydrostatic Stepless, 3 Hydraulic Ratios, 2 Mechanical Ranges (0-15 km/h, 0-40 km/h), Electro-Hydraulic Shuttle, RGS™ Reversible Drive System, Instant Cruise Control, Memo Cruise Control, Dual Memo Cruise Control, Intellifix, Fast Reverse, Drive Mode |
|
Clutch |
Hydrostatic Transmission |
|
Frame |
ACTIO™ Full Chassis with Oscillation, Steering, Isodiametric, 15° Longitudinal Oscillation |
|
Differential Lock |
Electro-Hydraulic Control, Simultaneous Front and Rear or Rear Only |
Suspension & Brakes
|
Specification |
Details |
|
Braking System |
Hydraulic Oil-Immersed Disc Brakes (Front and Rear), Rear Steering Brakes, Transmission Band Brake for Emergency and Parking, Optional Superbrake System |
Wheels & Tyres
|
Specification |
Details |
|
Tyre Size (Standard) |
31x15.50-15 Terra |
|
Tyre Size (Optional) |
320/70 R18, 33x15.50-15, 400/55-17.5, 19.0/45-17 |
Components & Features
|
Specification |
Details |
|
PTO Type |
Rear, Independent, 540/540E RPM, Progressive Electro-Hydraulic Engagement, Synchronized Groundspeed |
|
Hydraulic System |
2 Independent Pumps, On-Off Joystick, 2 Double-Acting Remote Valves (1 Float), Oil Return, 5 Rear Hydraulic Couplers, Uniflex Hydraulic Suspension, Optional Front Lift with 2 Couplers |
|
Rear 3-Point Hitch |
Category 2, 2400 kg (5291 lb) Capacity, Adjustable Lift Arms with Quick-Hitch Hooks, Uniflex Suspension |
|
Steering |
Hydraulic with Single Through-Rod Cylinder, RGS™ Reversible Drive System, Optional Steering Brakes |
|
Electrical System |
Multifunctional Digital Display, Battery Disconnector, Safe Start System, Optional LED Work Lights (2 Front + 2 Rear) |
|
Weight |
2150-2340 kg (4740-5159 lb, Roll-Bar); 2280-2470 kg (5027-5445 lb, ExtraComfort Cab) |
|
Cab Options |
Optional ExtraComfort Cab, ROPS Homologated, Soundproofed, Air-Conditioned, Opening Windscreen, 2 Work Lights, Suspended on Silent Blocks |
|
Ground Clearance |
240-465 mm (9.4-18.3 in, Depending on Tyres) |
|
Fuel Tank Capacity |
52 l (13.7 gal) |
|
Wheelbase |
1190 mm (46.9 in) |
|
Width |
1376-1925 mm (54.2-75.8 in) |
|
Warranty |
2 Years, Extendable to 4 Years (EXG Maximum Protection) |
