Antonio Carraro TR 5800 Infinity – 4WD Utility Tractor for Vineyards and Municipal Use
Specifications
|
Specification |
Details |
|
Tractor Model |
TR 5800 Infinity (4WD) |
|
Vehicle Category |
Utility Tractor |
|
Fuel Type |
Diesel |
|
Application |
Vineyards, Orchards, Urban Green Areas, Verges, Sports Grounds |
Frame & Drivetrain
|
Specification |
Details |
|
Engine |
Yanmar, 4 Cylinders, 16 Valves, 2091 cm³, Common Rail Direct Injection, Turbocharged, Liquid Cooled, Stage 5 |
|
Maximum Horsepower |
52 HP (37.9 kW) @ 2600 RPM |
|
Maximum Torque |
170 Nm @ 1690 RPM |
|
Transmission Type |
Hydrostatic Stepless, 3 Hydraulic Ratios, 2 Mechanical Ranges (0-12 km/h, 0-36 km/h), Electro-Hydraulic Shuttle, RGS™ Reversible Drive System, Optional Profi-Pack (Instant Cruise Control, Intellifix, Drive Mode, Fast Reverse) |
|
Clutch |
Hydrostatic Transmission |
|
Frame |
ACTIO™ Full Chassis with Oscillation, Steering, Isodiametric, 15° Longitudinal Oscillation |
|
Differential Lock |
Mechanically Operated Front, Electro-Hydraulic Rear, Optional Electro-Hydraulic Front |
Suspension & Brakes
|
Specification |
Details |
|
Braking System |
Hydraulic Oil-Immersed Rear Double Disc Brakes, Transmission Band Brake for Emergency and Parking, Mechanical Super Brake System |
Wheels & Tyres
|
Specification |
Details |
|
Tyre Size (Standard) |
260/70R16 |
|
Tyre Size (Optional) |
7.50-16, 280/70R18, 380/60-15, 320/65R18, 210/95R18, 250/80R18, 29x12.50-15 Terra, 29x12.50-15 Garden, 31x15.50-15 Terra, 33x15.50-15 |
Components & Features
|
Specification |
Details |
|
PTO Type |
Rear, Independent, 540/540E RPM, Optional 540/1000 RPM, Progressive Electro-Hydraulic Engagement, Synchronized with Transmission |
|
Hydraulic System |
Load-Sensing, 1 Double-Acting Float Valve, 1 Oil Return Valve, 3 Rear Hydraulic Connections, Optional Up to 13 Quick Couplers, Optional HRC Remote Control |
|
Rear 3-Point Hitch |
Category 1 and 2, 2200 kg (4850 lb) Capacity, Adjustable Lift Bars, Optional Uniflex Suspension, Optional Controlled Power and Positioning System |
|
Steering |
Hydraulic with 2 Pistons, RGS™ Reversible Drive System |
|
Electrical System |
Multifunctional Color Display, Battery Disconnect, Safe Start-Up System, Optional LED Work Lights (2 Front + 2 Rear) |
|
Weight |
1890-2030 kg (4167-4475 lb, Roll-Bar with Driver); 2040-2180 kg (4497-4806 lb, RedCab with Driver) |
|
Cab Options |
Optional RedCab, 6 Pillars, Soundproofed, Air-Conditioned, 360° Visibility, Opening Windows, Electric Wipers and Washers, USB Socket |
|
Ground Clearance |
216-340 mm (8.5-13.4 in, Depending on Tyres) |
|
Fuel Tank Capacity |
40 l (10.6 gal) |
|
Wheelbase |
1210 mm (47.6 in) |
|
Width |
972-1559 mm (38.3-61.4 in) |
|
Warranty |
2 Years, Extendable to 4 Years (EXG Maximum Protection) |
