Antonio Carraro TONY 8900 TRG T4 – 4WD Vineyard Tractor for Precision Tasks
Specifications
|
Specification |
Details |
|
Tractor Model |
TONY 8900 TRG T4 (4WD) |
|
Vehicle Category |
Vineyard Tractor |
|
Fuel Type |
Diesel |
|
Application |
Vineyards, Orchards, Narrow Crop Rows, Steep Slopes, Low Canopy Work |
Frame & Drivetrain
|
Specification |
Details |
|
Engine |
KUBOTA Diesel Direct Injection, 4 Cylinders, 16 Valves, 3769 cc, Stage 5, Common Rail, Turbo, Water Cooling |
|
Power |
54.6 kW / 74.2 hp @ 2400 rpm |
|
Torque Max |
305 Nm @ 1500 rpm |
|
Transmission |
Hybrid mechanical-hydrostatic transmission, 4-position speed selector with “SIM” (Shift In Motion) servo control technology, Stepless speed variation in both forward and reverse from 0 to 40 km/h, “Automotive” device, Electronically controlled engine speed and rpm (RPM recall, Cruise Control, combined, IntelliFix, diagnostics functions) |
|
Drive Disengagement |
Electrohydraulic control on the front |
|
Chassis |
ACTIO™ full chassis with oscillation, Reversible RGS™, Steering wheels, Differential four-wheel drive, Front/rear final drive |
|
Differential Lock |
Rear or front/rear differential lock with electrohydraulic control |
Suspension & Brakes
|
Specification |
Details |
|
Brakes |
Front and rear oil bath disc brakes and hydraulically controlled rear steering brake, Automatic oil bath multi-disc parking and emergency brake on transmission |
|
Steering |
Hydraulic steering wheel with through-rod cylinder |
Wheels & Tyres
|
Specification |
Details |
|
Wheels |
Front: 280/85 R20, 320/70 R20, 280/70 R18, 300/80-15.3; Rear: 320/85 R24, 360/70 R24, 420/65 R24, 360/70 R20 |
|
Minimum External Width |
1070 mm (280/85 R20 - 320/85 R24), 1135 mm (320/70 R20 - 420/65 R24), 1185 mm (320/70 R20 - 360/70 R24), 1130 mm (280/70 R18 - 360/70 R20), 1080 mm (280/70 R18 - 360/70 R20 Low Profile), 1170 mm (300/80-15.3 - 360/70 R20 Low Profile) |
Components & Features
|
Specification |
Details |
|
PTO |
Rear, independent 540/540E rpm with progressive and synchronised electro-hydraulic clutch at all speeds, Profile 1” 3/8 with 6 splines with facilitated engagement, Start inhibit switch on shuttle reverser, PTO selector and seat |
|
Hydraulic System |
Hydraulic equipment with 2 separate hydraulic pumps, Hydraulic flow rate up to 45 litres/min to spool valves, Auxiliary rear hydraulic equipment with 2 double-acting spool valves (1 floating) and 1 single-acting, 1 oil reflow with 6 rear hydraulic outlets + 2 electronically controlled double-acting with mini-pins (4 mini-pins), Operating Pressure 160 bar |
|
Rear Hydraulic Lift |
Draft and position control with damping for road travel, Lifting links with quick couplings in cat. 2 quick couplings, Lifting capacity 2400 kg |
|
Towing Device |
Rear adjustable height tow hitch, Front tow hitch |
|
Platform |
Suspended on Silent Block, Forward foldable front safety roll bar with facilitator |
|
Weight |
With roll bar: 2515–2635 kg, With AIR cab: 2745–2865 kg, With roll bar TRG Low: 2475–2555 kg, With AIR cab TRG Low: 2705–2785 kg |
|
Tank Capacity |
50 litres |
|
Warranty |
2 years warranty, with the opportunity to extend the guarantee up to 4 years |
