Antonio Carraro Tigre 3800 – 4WD Utility Tractor for Small Farms
Specifications
|
Specification |
Details |
|
Tractor Model |
Tigre 3800 (4WD) |
|
Vehicle Category |
Utility Tractor |
|
Fuel Type |
Diesel |
|
Application |
Small Farms, Allotments, Greenhouses, Parks, Gardens, Sports Fields, Municipal Areas |
Frame & Drivetrain
|
Specification |
Details |
|
Engine |
Yanmar, 3 Cylinders, 1331 cm³, Direct Injection, Natural Aspiration, Stage 5 |
|
Maximum Horsepower |
25.7 HP (18.9 kW) @ 2800 RPM |
|
Maximum Torque |
86.8 Nm @ 1200 RPM |
|
Transmission Type |
Mechanical, 8 Forward + 4 Reverse, Assisted Changes |
|
Clutch |
Dry Single-Disk, Optional Multi-Disk in Oil Bath with Independent Engagement/Disengagement |
|
Frame |
ACTIO™ Full Chassis with Oscillation, Steering, Isodiametric |
Suspension & Brakes
|
Specification |
Details |
|
Braking System |
Drum Service Brakes on Rear Wheels, Parking Brakes, Optional Steering Brakes |
|
Differential Lock |
Front and Rear |
Wheels & Tyres
|
Specification |
Details |
|
Tyre Size (Standard) |
7.50-16 in |
|
Tyre Size (Optional) |
7.5L-15, 29x12.50-15, 6.50-16, 260/70 R16 |
Components & Features
|
Specification |
Details |
|
PTO Type |
Rear, Standard 540 RPM, Synchronized with All Gear Speeds, Optional Independent Engagement/Disengagement |
|
Hydraulic System |
30 l/min Flow Rate, 1 Double-Acting Distributor with Floating Position, 2 Quick Couplings |
|
Rear 3-Point Hitch |
Category 1 and 1N, 850 kg (1874 lb) Capacity, Adjustable Tie-Rods |
|
Steering |
Hydraulic |
|
Electrical System |
Backlit Analogue/Digital Dashboard, Fuel Level and Water Temperature Gauges, Indicator LEDs, Digital PTO Rev Display, Acoustic and Visual Alarms, Halogen Headlamps, 12V 7-Pole/Single-Pole Outlet, Claxon |
|
Weight |
1075 kg (2369 lb, Roll-Bar) |
|
Cab Options |
None |
|
Ground Clearance |
275 mm (10.8 in) |
|
Fuel Tank Capacity |
30 l (7.9 gal) |
|
Wheelbase |
1085 mm (42.7 in) |
|
Width |
950-1240 mm (37.4-48.8 in) |
|
Warranty |
2 Years, Extendable to 4 Years (EXG Maximum Protection) |
