Antonio Carraro SX 7800 S – 4WD Utility Tractor for Vineyards and Greenhouses
Specifications
|
Specification |
Details |
|
Tractor Model |
SX 7800 S (4WD) |
|
Vehicle Category |
Utility Tractor |
|
Fuel Type |
Diesel |
|
Application |
Vineyards, Greenhouses, Narrow Crop Rows |
Frame & Drivetrain
|
Specification |
Details |
|
Engine |
Yanmar, 4 Cylinders, 16 Valves, 3319 cm³, Common Rail Direct Injection, Stage 5 |
|
Maximum Horsepower |
70.3 HP (51.7 kW) @ 2500 RPM |
|
Maximum Torque |
236 Nm @ 1600 RPM |
|
Transmission Type |
Synchronized, 16 Forward + 16 Reverse, Synchronized Inverter, RGS™ Reversible Drive System |
|
Clutch |
Mechanic Control, No Adjustment Required |
|
Frame |
ACTIO™ Full Chassis with Oscillation, Articulated, Isodiametric, 15° Longitudinal Oscillation |
|
Differential Lock |
Electro-Hydraulic Control, Front and Rear or Rear Only |
Suspension & Brakes
|
Specification |
Details |
|
Braking System |
Hydraulic Front and Rear Oil-Immersed Disc Brakes, Band-Type Emergency and Parking Brake on Transmission |
Wheels & Tyres
|
Specification |
Details |
|
Tyre Size (Standard) |
320/70 R24 |
Components & Features
|
Specification |
Details |
|
PTO Type |
Rear, Independent, 540/540E RPM, Progressive Electro-Hydraulic Engagement, Synchronized with Gear Speeds |
|
Hydraulic System |
2 Separate Hydraulic Pumps, 3-Lever Ancillary System, 160 bar Operating Pressure, Optional JPM Proportional Joystick |
|
Rear 3-Point Hitch |
Category 1 and 2, 2420 kg (5335 lb) Capacity, Adjustable Lifting Arms with Quick-Release Laterally Moving Couplings |
|
Steering |
Hydraulic, Adjustable Steering Wheel, RGS™ Reversible Drive System |
|
Electrical System |
Multifunctional Digital Console, Battery, Battery Isolation Switch, Electrical Power Point, Safe Start System |
|
Weight |
2090 kg (4608 lb, Roll-Bar); 2230 kg (4916 lb, StarLight Cab) |
|
Cab Options |
Optional StarLight Cab, Soundproofed, Air-Conditioned, Roof Window, Optional Activated Carbon Filter, Suspended on Silent Blocks |
|
Ground Clearance |
390 mm (15.4 in) |
|
Fuel Tank Capacity |
50 l (13.2 gal) |
|
Wheelbase |
1225 mm (48.2 in) |
|
Width |
1410 mm (55.5 in) |
|
Warranty |
2 Years, Extendable to 4 Years (EXG Maximum Protection) |
