Antonio Carraro SRG 7600 Infinity – 4WD Utility Tractor for Greenhouses and Raised Beds
Specifications
|
Specification |
Details |
|
Tractor Model |
SRG 7600 Infinity (4WD) |
|
Vehicle Category |
Utility Tractor |
|
Fuel Type |
Diesel |
|
Application |
Raised Bed Crops, Greenhouses, Vineyards, Orchards |
Frame & Drivetrain
|
Specification |
Details |
|
Engine |
Kohler, 4 Cylinders, 16 Valves, 2482 cm³, Common Rail Direct Injection, Intercooler Turbo, Stage 5 |
|
Maximum Horsepower |
75.3 HP (55.4 kW) @ 2300 RPM |
|
Maximum Torque |
310 Nm @ 1500 RPM |
|
Transmission Type |
Hybrid Mechanical-Hydrostatic, 3 Hydraulic Speeds, 2 Mechanical Ranges (0-15 km/h, 0-40 km/h), Electro-Hydraulic Shuttle, RGS™ Reversible Drive System, Automotive Device, Instant Cruise Control, Memo Cruise Control, Dual Memo Cruise Control, Intellifix, Fast Reverse |
|
Clutch |
Hydrostatic Transmission |
|
Differential Lock |
Electro-Hydraulic Control, Rear |
|
Frame |
ACTIO™ Full Chassis with Oscillation, Articulated, 15° Longitudinal Oscillation |
Suspension & Brakes
|
Specification |
Details |
|
Braking System |
Hydraulic Front/Rear Oil-Immersed Disc Brakes, Emergency Band Brake on Transmission |
Wheels & Tyres
|
Specification |
Details |
|
Tyre Size |
Maximum Diameter 32 in |
Components & Features
|
Specification |
Details |
|
PTO Type |
Rear, Independent, 540/540E RPM, 2-Speed Electro-Hydraulic Clutch |
|
Hydraulic System |
2 Independent Pumps, 2 Double-Acting Spool Valves, 1 Single-Acting Spool Valve, 1 Oil Reflow, 6 Rear Hydraulic Outlets |
|
Rear 3-Point Hitch |
Category 2, 2300 kg (5071 lb) Capacity, Lifting Bars with Quick Couplings |
|
Steering |
Hydraulic, Articulated Frame, RGS™ Reversible Drive System |
|
Electrical System |
Multifunctional Digital Display, Battery Disconnect |
|
Weight |
2620 kg (5776 lb, Roll-Bar) |
|
Cab Options |
Optional RedCab, 6 Pillars, Soundproofed, Air-Conditioned, 360° Visibility, Opening Windows |
|
Ground Clearance |
615 mm (24.2 in) |
|
Fuel Tank Capacity |
40 l (10.6 gal) |
|
Wheelbase |
1185 mm (46.7 in) |
|
Width |
1100-1500 mm (43.3-59.1 in) |
|
Warranty |
2 Years, Extendable to 4 Years (EXG Maximum Protection) |
