Antonio Carraro MACH 2 R T4 – 4WD Vineyard Tractor for Precision Tasks
Specifications
|
Specification |
Details |
|
Tractor Model |
MACH 2 R T4 (4WD) |
|
Vehicle Category |
Vineyard Tractor |
|
Fuel Type |
Diesel |
|
Application |
Vineyards, Orchards, Nurseries, Extreme Terrains |
Frame & Drivetrain
|
Specification |
Details |
|
Engine |
KUBOTA, 4 Cylinders, 16 Valves, 3769 cc, Stage 5, Common Rail, Turbo, Water Cooling |
|
Power |
54.6 kW / 74.2 hp @ 2400 rpm |
|
Max Torque |
305 Nm @ 1500 rpm |
|
Transmission |
32-speed synchronised gearbox: 16 forward + 16 reverse gears with synchronised shuttle |
|
Frame |
ACTIO™ integral oscillating frame, 2 rear tracks and 2 front steering drive wheels, RGS™ reversible drive system |
Suspension & Brakes
|
Specification |
Details |
|
Brakes |
Service: front/rear oil-immersed disc brakes and steering brakes on rear with hydraulic control, Emergency and parking: band brakes on the transmission |
Wheels & Tyres
|
Specification |
Details |
|
Tyres |
Front: 11.2 R20 |
Components & Features
|
Specification |
Details |
|
Power Take-Off |
Independent 540/540E rpm, synchronised in all gears |
|
Hydraulic System |
2 pumps with independent circuits, 2 double-acting remote valves including 1 float + oil return |
|
Rear Power Lift |
3-point linkage with Damping function for road transfer, Adjustable lifting bars with Cat. 2 sliding quick hitches, Lifting capacity 2300 kg |
|
Towing Device |
Category "C" height-adjustable rear tow hook, Front tow hook |
|
Weight |
With roll bar: 3050 kg, With cab: 3200 kg |
|
Warranty |
2 years warranty, with the opportunity to extend the guarantee up to 4 years |
