Specification

Details

Tractor Model

AV 2.85 L (4WD)

Vehicle Category

Utility Tractor

Fuel Type

Diesel

Application

Vineyards, Narrow Rows, Sloping Terrains

Specification

Details

Engine

FPT F28 Stage V, 4 Cylinders, 2 Valves, 2800 cm³, Common Rail Injection, Turbocharged with Aftercooler, DOC/DPF

Maximum Horsepower

74.8 HP (55 kW) @ 2300 RPM

Maximum Torque

358 Nm @ 1500 RPM

Transmission Type

Synchronized, 24 Forward + 12 Reverse (or 24+24 Optional), 4 Gears, 3 H/M/L Ranges with Electro-Hydraulic Hi-Lo and Power Reverser, Dry 12” Cerametallic Clutch

Clutch

Dry, 12” Cerametallic

Front Axle

Four Wheel Drive, Carraro, 55° Steering Angle, Flange-to-Flange 990 mm, Mechanical or Hydraulic Engagement, Electro-Hydraulic Rear Differential Lock, Suspended IFAS Axle

Specification

Details

Braking System

Mechanical and Hydraulic, 10 Oil-Bath Disc Brakes (Front/Rear)

Specification

Details

Tyre Size (Front, Standard)

280/70R18

Tyre Size (Rear, Standard)

380/70R28

Specification

Details

PTO Type

Independent, 540/540E or 540/1000 RPM, Electro-Hydraulic Engagement

Hydraulic System

Load-Sensing, 2 or 3 Mechanical Distributors (1 SE/DE Detent + 1 SE/DE Floating, Optional 3rd SE/DE or 4th Electro-Hydraulic), 1 Free Oil Flow, 60+27 l/min (2 Pumps) or 60+27+27 l/min (3 Pumps) @ 2300 RPM, Hydraulic Power Lift with Adjustable Parallel Blocks (Category 1 or 2), Vertical Mechanical Tie Rod

Rear 3-Point Hitch

Category 1 or 2, 2600 kg (5732 lb) Capacity

Steering

Hydraulic, Adjustable and Telescopic Steering Column

Electrical System

80 Ah Battery, 100 A Alternator, 3.2 kW Starter Motor, 2 Front + 2 Rear Halogen Oval Lights, H3/H4 Lights (Optional), Rotating Security Light (Optional)

Weight

2940 kg (6477 lb, Cab)

Cab Options

Air-Conditioned Cab, 4 Uprights, Category 2, on Silent Block

Warranty

2 Years, Extendable to 4 Years

Width

1436-1604 mm (56.5-63.1 in)
