ACE 6500 – Agricultural Tractor by ACE

Images:

1

2

Specifications

Specification	Details
Tractor Model	6500
Vehicle Category	Tractor
Fuel Type	Diesel
Application	Agricultural Tractor

Frame & Drivetrain

Specification	Details
Engine Type	4 Cylinder, Water Cooled, Naturally Aspirated Diesel Engine (Cold Start Kit Optional)
Engine Power	61.2 HP / 45 kW
Number of Cylinders	Four
Bore/Stroke	105/118 mm
Engine Capacity	4088 CC
Engine Rated RPM	2200
Air Cleaner	Dry Air Cleaner with Clogging Sensor
Max Torque	255 Nm @ 1450 RPM
Clutch	Double Clutch
Transmission Type	Synchromesh with F/R Synchro Shuttle
Number of Gears	12 Forward + 12 Reverse
Speed Range	Forward: 1.50–30.85 km/h @ 2200 RPM

Suspension & Brakes

Specification	Details
Brakes	Oil Immersed Disc Brakes, Mechanically Actuated
Steering Type	Power Steering

Wheels & Tyres

Specification	Details
Front Tyres	7.50 x 16 inches (2WD); 9.5 x 24 inches (4WD)
Rear Tyres	16.9 x 28 inches

Components & Features

Specification	Details
Drive	2WD / 4WD
Maximum Lifting Capacity	2200 kg
Hydraulics Type	Automatic Draft Control, 3 Point Linkage CAT II, 1SA+1DA Auxiliary Hydraulic Circuit
Power Take Off	Independent PTO, 540/540 E, Mechanically Actuated, Hand Operated
Total Weight	2600 kg (2WD); 2785 kg (4WD)
Electrical System	12V, 88 Ah Battery, 12V, 65 Amp Alternator, Seven Pin (Round) Trailer Socket
Fuel Tank Capacity	65 Litres
Additional Features	Trailer Hitch (Rotating Type, Optional), Horizontally Adjustable Driver Seat, Fuel Indicator Gauge, Front Weight Carrier (Hanging Weight Optional), Rear Weight
Wheel Base	2135 mm (2WD); 2235 mm (4WD)
Overall Length	3990 mm
Overall Width	1940 mm
Height	2600 mm
Ground Clearance	400 mm (2WD); 380 mm (4WD)
Turning Diameter	With Brakes: 7260 mm (L) - 7130 mm (R) (2WD); 7989 mm (L) - 7780 mm (R) (4WD); Without Brakes: 8420 mm (L) - 8570 mm (R) (2WD); 9003 mm (L) - 8790 mm (R) (4WD)

* All the images are screenshots!
* Data has been taken from official website (Publicly Available)!
