Specification

Details

Model

F-450 XL

Vehicle Category

Heavy Duty Pickup

Fuel Type

Diesel

Application

Work truck, heavy duty

Starting Price (2025)

$61,955 (Regular Cab), $63,455 (Crew Cab), includes destination charge

Color Options

Exterior: Oxford White, Iconic Silver, Carbonized Gray, Agate Black Metallic, Rapid Red Metallic, Star White Metallic, Argon Blue Metallic, Marsh Gray Metallic; Interior: Medium Dark Slate vinyl

Specification

Details

Engine

6.7L Power Stroke V8 Turbo Diesel (475 HP, 1,050 lb-ft), available 6.7L High Output Power Stroke V8 Turbo Diesel (500 HP, 1,200 lb-ft)

Gross Horsepower

475 HP @ 2600 rpm (6.7L), 500 HP @ 2600 rpm (6.7L High Output)

Torque

1,050 lb-ft @ 1600 rpm (6.7L), 1,200 lb-ft @ 1600 rpm (6.7L High Output)

Transmission Type

TorqShift 10-speed automatic

Drivetrain

Four-Wheel Drive (4x4); DRW configuration only

Max Towing Capacity

40,000 lbs (Regular Cab, 6.7L High Output diesel, gooseneck), 30,000 lbs conventional (Crew Cab)

Specification

Details

Front Suspension

Mono-beam with coil springs, stabilizer bar

Rear Suspension

Solid axle with leaf springs

Brakes

Four-wheel disc brakes with ABS, electronic brakeforce distribution

Specification

Details

Seating

3 (Regular Cab), 5-6 (Crew Cab)

Interior Features

8-inch touchscreen with SYNC 4, Apple CarPlay, Android Auto, 4-speaker audio system, USB ports (2 "A"), single-zone manual climate control, vinyl seats, 8-way manual driver seat, 6-way manual passenger seat, 40/20/40 front bench seat (Regular Cab), 60/40 split-folding rear seat (Crew Cab), Ford Co-Pilot360 (pre-collision assist with automatic emergency braking, pedestrian detection, forward collision warning, rearview camera, auto high beams), 8-inch digital gauge display, cruise control, under-seat storage (Crew Cab), available trailer brake controller

Exterior Features

17-inch forged polished aluminum wheels, 245/75R17 all-terrain tires, halogen headlights, LED taillights, 8-ft bed (50.6 in. wide), manual tailgate lock, manual sideview mirrors, black grille, black bumpers, available High-Capacity Trailer Tow Package (hitch, 7-pin connector, trailer sway control)

Fuel Economy and Performance

EPA-estimated 10/14 MPG (city/highway, 6.7L diesel 4x4), 475 HP and 1,050 lb-ft (6.7L), 500 HP and 1,200 lb-ft (6.7L High Output), 0–60 mph in 6.8 seconds (6.7L), 6.5 seconds (6.7L High Output), top speed 110 mph, payload up to 6,965 lbs, 5 drive modes (Normal, Eco, Sport, Tow/Haul, Slippery)

Cargo Volume

81.0 cu.ft. (8-ft bed)

Fuel Tank

29.0 gal (Regular Cab, 142-inch wheelbase), 34.0 gal (Crew Cab, 164-inch or 176-inch wheelbase)

Weight

7,600 lbs (Regular Cab 4x4, 6.7L), 8,500 lbs (Crew Cab 4x4, 6.7L High Output)

Width

96.0 in. (excluding mirrors)

Length

231.8 in. (Regular Cab, 8-ft bed), 266.2 in. (Crew Cab, 8-ft bed)

Max Height

81.0 in. (4x4)

Ground Clearance

8.3 in.
